| Specification |
Details |
| Printer Technology |
• Technology: Epson Micro Piezo™ print head
• Nozzle Configuration: 180 Nozzles Black, 180 Nozzles per Color
• Minimum Droplet Size: 1.5 pl, with Variable-Sized Droplet Technology
• Ink Technology: Dye Ink
• Printing Resolution: 5,760 x 1,440 DPI
• Category: Photo |
| All-in-One Functions |
• Print: Yes
• Number of Colors: 6 colors
• ISO/IEC 24734 Printing Speed: 8 pages/min Monochrome, 8 pages/min Colour
• Printing Speed:
- 22 pages/min Monochrome (plain paper 75 g/m²)
- 22 pages/min Colour (plain paper 75 g/m²)
- 13 seconds per 10 x 15 cm photo (Epson Premium Glossy Photo Paper)
• Print From: USB, PC (Wireless), Mobile Device (WiFi Direct), Mobile Device (Wireless) |
| Ink & Color Info |
• Colors: Black [Dye], Cyan [Dye], Light Cyan [Dye], Yellow [Dye], Magenta [Dye], Light Magenta [Dye]
• Color Capacity: 70ml per bottle (all colors) |
| Paper Support |
• Paper Formats: A4, A5, A6, B5, C6 (Envelope), DL (Envelope), No. 10 (Envelope),
Letter, Plastic Cards, A3+, A3
• Duplex: Manual
• Paper Tray Capacity:
- 100 Sheets Standard
- 100 Sheets Maximum
- 20 Photo Sheets
• Rear Paper Path: Yes
• Media Handling: Borderless Print, CD/DVD Print |
| Energy Use |
• Sleep Mode: 0.6 Watt
• Printing: 19 Watt
• Ready: 4.4 Watt
• Power Off: 0.2 Watt
• TEC: 0.13 kWh/week
• Supply Voltage: AC 100 V – 240 V |
| Physical Features |
• Dimensions (W x D x H): 523 x 369 x 150 mm
• Weight: 8 kg
• Noise Level:
- Operation: 6.1 B (A) with Epson Premium Glossy Photo Paper / Photo RPM mode
- Operation: 48 dB (A) |
| Compatibility |
• Operating Systems: Mac OS X 10.9.5 or later,
Windows 10, Windows 11, Windows 7, Windows 8, Windows 8.1,
Windows Vista, Windows XP (32/64-bit), Windows Server (Various) |
| Interfaces & Network |
• Interfaces: Wireless LAN IEEE 802.11a/b/g/n, Wi-Fi Direct
• WLAN Security: WEP 64 Bit, WEP 128 Bit,
WPA PSK (TKIP), WPA2 PSK (AES), WPA3-SAE (AES) |
| Mobile & Cloud Printing |
• Mobile Apps: Epson iPrint App, Epson Smart Panel App |
| What's in the Box |
• Included Items:
6 x 70ml individual ink bottles (Bk, C, Y, M, Lc, LM)
Main unit
Power cable
Setup guide
Warranty document |
| Emulations |
• Emulation: ESC/P-R |
| Included Bottle Yield |
• Black Yield: 2,600 pages
• Colour Yield: 5,400 pages, 1,500 photos |
