Specifications
Type:
Cooling Only
Climate:
T3
Control Type:
Remote
Power Supply (Ph-V-Hz):
1Ph-220-240V~50Hz
Voltage Range (V):
198~264
Cooling Performance (T1)
Capacity:
22100 BTU/h
Capacity:
6480 kW
Rated Power Input:
1788 W
Rated Current:
8.3 A
EER:
12.360 BTU/h-W
Max Power Input:
3300 W
Max Current:
15.0 A
Star Rating
Kuwait:
7 Stars
Rated Cooling Performance (T3)
Capacity:
20500 BTU/h
Capacity:
6000 kW
Rated Power Input:
2296 W
Rated Current:
10.3 A
EER:
8.929 BTU/h-W
Max Power Input:
3300 W
Max Current:
15.0 A
Rated Cooling Performance (T4)
Capacity:
20500 BTU/h
Capacity:
6000 kW
Rated Power Input:
2296 W
Rated Current:
10.3 A
EER:
8.929 BTU/h-W
Max Power Input:
3300 W
Max Current:
15.0 A
Power Rating Per Refrigeration Ton (PRT):
1.346 kW/RT
Annual Energy Consumption
Annual Energy Consumption (Oman/Bahrain):
4828 kWh/year
Annual Energy Consumption (UAE):
4592 kWh/year
Performance
Moisture Removal:
2.4 L/h
Indoor Noise Level:
56 dB(A)
Outdoor Noise Level:
60 dB(A)
Compressor Type:
Rotary
Indoor Air Flow (High):
1500 m³/h
Indoor Unit
Dimension (W×D×H):
1005×321×220 mm
Packing Dimension:
1096×390×297 mm
Net/Gross Weight:
13/16 kg
Outdoor Unit
Dimension (W×D×H):
927×380×699 mm
Packing Dimension:
960×430×732 mm
Net/Gross Weight:
42/45 kg
Refrigerant Piping
Liquid Side / Gas Side:
φ6 (1/4") / φ12 (1/2")
Maximum Refrigerant Pipe Length:
15 m
Maximum Difference in Level:
5 m
Pressure & Refrigerant
High Pressure:
4.5 MPa
Low Pressure:
1.9 MPa
Refrigerant:
R32 / 0.82 kg
Additional Information
Ambient Temperature:
-15~60°C
Suitable Area:
35~55 m²
Connecting Wiring:
0.75 mm² × 4 Core
Nominal Quantity 40'HQ:
158 Units
