Specifications
Type: Cooling Only
Climate: T3
Control Type: Remote Control
Power Supply (Ph-V-Hz): 1Ph, 220-240V~, 50Hz
Voltage Range: 198–264V
Cooling Performance (T1)
Capacity: 18,700 BTU/h (5.49 kW)
Rated Power Input: 1,547W
Rated Current: 7.2A
EER: 12.088 BTU/h/W
Maximum Power Input: 2,600W
Maximum Current: 12A
Cooling Performance (T3)
Capacity: 18,200 BTU/h (5.34 kW)
Rated Power Input: 1,956W
Rated Current: 8.8A
EER: 9.305 BTU/h/W
Maximum Power Input: 2,600W
Maximum Current: 12A
Cooling Performance (T4)
Capacity: 17,900 BTU/h (5.246 kW)
Rated Power Input: 1,941W
Rated Current: 8.8A
EER: 9.222 BTU/h/W
Maximum Power Input: 2,600W
Maximum Current: 12A
Power Rating per Refrigeration Ton (PRT): 1.301 kW/RT
Performance
Kuwait Star Rating: 7 Stars
Moisture Removal: 1.8 L/h
Indoor Noise Level: 52 dB(A)
Outdoor Noise Level: 56 dB(A)
Indoor Air Flow (High): 1,100 m³/h
Compressor Type: Rotary
Indoor Unit
Dimensions (W × D × H): 1005 × 321 × 220 mm
Packing Dimensions: 1096 × 390 × 297 mm
Net / Gross Weight: 13 / 16 kg
Outdoor Unit
Dimensions (W × D × H): 853 × 349 × 602 mm
Packing Dimensions: 890 × 385 × 628 mm
Net / Gross Weight: 36 / 39 kg
Refrigerant Piping
Liquid / Gas Pipe Size: 1/4" / 1/2"
Maximum Pipe Length: 15 m
Maximum Height Difference: 5 m
Pressure & Refrigerant
High Pressure: 4.5 MPa
Low Pressure: 1.9 MPa
Refrigerant: R32 (0.72 kg)
Additional Information
Ambient Operating Temperature: -15°C to 60°C
Suitable Area: 20–35 m²
Connecting Wiring: 1.5 mm² × 4 Core
40'HQ Container Loading: 200 Units
