| Specification |
Details |
| Performance - Processor |
Intel Core™ Ultra 5 226V
8C (4P + 4LPE) / 8 Threads
Max Turbo up to 4.5 GHz
8MB Intel® Smart Cache |
| Performance - AI PC Category |
Copilot+ PC |
| Performance - NPU |
Integrated Intel® AI Boost (Up to 40 TOPS) |
| Performance - Graphics |
Integrated Intel® Arc™ Graphics 130V |
| Performance - Chipset |
Intel® SoC Platform |
| Performance - Memory |
16GB LPDDR5X-8533 (Soldered, MoP) |
| Performance - Memory Slots |
Lunar Lake: Soldered, No Slots, Dual-Channel |
| Performance - Max Memory |
16GB (Not Upgradable) |
| Performance - Storage |
512GB SSD M.2 2242 PCIe® 4.0 x4 NVMe® (Opal 2.0) |
| Performance - Storage Slot |
1× M.2 2280 PCIe® 4.0 x4 Slot |
| Performance - Max Storage Support |
Up to 1TB M.2 2280 SSD |
| Performance - Card Reader |
No |
| Performance - Audio Chip |
High Definition Audio (Senary SN6147 Codec) |
| Performance - Speakers |
Stereo Speakers (2W × 2), Dolby Atmos®, HARMAN Audio |
| Performance - Microphone |
Dual Array Microphones |
| Performance - Camera |
FHD 1080p + IR Hybrid with Privacy Shutter |
| Performance - Battery |
48Wh |
| Performance - Power Adapter |
65W USB-C® (3-pin) |
| Design - Display |
16" WUXGA (1920 × 1200) IPS
300 nits, Anti-glare
45% NTSC, 60Hz |
| Design - Touchscreen |
No |
| Design - Screen-to-Body Ratio |
90.7% |
| Design - Pen Support |
Not Supported |
| Design - Keyboard |
Backlit, Arabic |
| Design - Dimensions (W x D x H) |
356 × 249 × 10.1 / 17.05 (front/rear), 21.15 mm (max)
14.01 × 9.80 × 0.40 / 0.67 (front/rear), 0.83 in (max) |
| Design - Weight |
Starting at 1.61 kg (3.55 lbs) |
| Design - Case Color |
Black |
| Design - Case Material |
Aluminium (Top & Bottom) |
| Software - Operating System |
None |
| Software - Bundled Software |
None |
| Connectivity - WLAN & Bluetooth |
Intel® Wi-Fi® 6E AX211 (802.11ax 2×2) + Bluetooth 5.3 |
| Connectivity - WWAN |
Not Supported |
| Connectivity - SIM Card |
No |
| Connectivity - Ethernet |
100 / 1000M (RJ-45) |
| Connectivity - NFC |
No |
| Connectivity - Standard Ports |
USB-A (5Gbps / USB 3.2 Gen 1)
USB-A (10Gbps / USB 3.2 Gen 2, Always On)
USB-C® (Thunderbolt™ 4 / USB4® 40Gbps, PD 45-65W, DisplayPort™ 2.1)
HDMI® 2.1 (Up to 4K@60Hz)
Headphone/Microphone Combo (3.5mm)
Ethernet (RJ-45) |
| Connectivity - Optional Ports |
Additional USB-C® (Thunderbolt™ 4 / USB4® 40Gbps, PD, DisplayPort™ 2.1) |
| Connectivity - Docking |
Supported via Thunderbolt™ or USB-C® Docking Solutions |
| Security & Privacy - ThinkShield |
Integrated Hardware, Software & Supply Chain Security Solution |
| Security & Privacy - Security Chip |
Discrete TPM 2.0 |
| Security & Privacy - Physical Locks |
Kensington Nano Security Slot™ (2.5 × 6 mm) |
| Security & Privacy - Smart Card Reader |
No |
| Security & Privacy - Fingerprint Reader |
Touch Style, Integrated in Power Button |
| Security & Privacy - Other Security |
Camera Privacy Shutter
IR Camera for Windows Hello (Facial Recognition) |
| Manageability - System Management |
Non-vPro® |
| Warranty |
1-Year |
| Service - Included Upgrade |
None |
| Accessories - Bundled Accessories |
Lenovo® 15.6" Laptop Casual Toploader |
| Certifications - Green Certifications |
ErP Lot 6/26
RoHS Compliant
TCO Certified (Generation 10) |
| Certifications - MIL-Spec Test |
MIL-STD-810H Military Test Passed |
| Certifications - Other Certifications |
TÜV Rheinland® Low Blue Light (Software Solution) |
| Model Information - Model |
22AY0004GR |
