TypeCooling only, ON/OFF
ClimateT3
Control typeRemote
Power supply (Ph-V-Hz)1Ph-220-240V~50Hz
Voltage Range (V)198~264
Cooling Performance (T1) - Capacity (Btu/h)18200
Cooling Performance (T1) - Capacity (KW)5334
Cooling Performance (T1) - Rated power Input (W)1529
Cooling Performance (T1) - Rated current (A)6.7
Cooling Performance (T1) - EER (Btu/h-W)11.903
Cooling Performance (T1) - Max power Input (W)2300
Cooling Performance (T1) - Max current (A)12.5
Star Rating - Oman7
Star Rating - Bahrain6
Star Rating - Kuwait5
Star Rating - UAE2
Rated Cooling Performance (T3) - Capacity (Btu/h)16200
Rated Cooling Performance (T3) - Capacity (Kw)4748
Rated Cooling Performance (T3) - Rated power Input (W)1748
Rated Cooling Performance (T3) - Rated current (A)8.0
Rated Cooling Performance (T3) - EER (Btu/h-W)9.268
Rated Cooling Performance (T3) - Max power Input (W)2300
Rated Cooling Performance (T3) - Max current (A)12.5
Rated Cooling Performance (T4) - Capacity (Btu/h)15300
Rated Cooling Performance (T4) - Capacity (Kw)4484
Rated Cooling Performance (T4) - Rated power Input (W)1841
Rated Cooling Performance (T4) - Rated current (A)7.8
Rated Cooling Performance (T4) - EER (Btu/h-W)8.311
Rated Cooling Performance (T4) - Max power Input (W)2300
Rated Cooling Performance (T4) - Max current (A)12.5
Rated Cooling Performance (T4) - Power Rating Per Refrigeration Ton(PRT) (kW/RT)1.444
Annual energy consumption(OAMN/Bahrain) (kwh/year)4128
Annual energy consumption(UAE) (kwh/year)3496
Moisture removal (Liters/h)1.8
Indoor noise level (Hi/Me/Lo/Mute) (dB(A))46
Outdoor noise level (dB(A))53
Compressor - ModelASL180MV-C7EUT
Compressor - TypeRotary
Compressor - BrandHighly
Expansion deviceCapillary
Indoor air flow (Hi) (m3/h)1100
Indoor unit - Dimension(W*D*H) (mm)1005×321×220
Indoor unit - Packing (W*D*H) (mm)1096×390×297
Indoor unit - Net/Gross weight (Kg)12 / 14
Outdoor unit - Dimension(W*D*H) (mm)927×380×699
Outdoor unit - Packing (W*D*H) (mm)960×430×732
Outdoor unit - Net/Gross weight (Kg)41 / 43
Refrigerant piping - Liquid side/ Gas side (mm(inch))φ6(1/4")/φ12(1/2")
Refrigerant piping - Max. refrigerant pipe length (m)15
Refrigerant piping - Max. difference in level (m)5
Pressure - High(DP) (MPa)4.5
Pressure - Low(SP) (MPa)1.9
RefrigerantR410A/0.720kg
Ambient temperature (℃)15~55
Suitable area (㎡)20~35
Connecting Wiring - Size x Core number1.5m㎡×3
Nominal Qty 40'HQ155
